Detailed Product Description
The Hikvision DS-2CE76H0T-ITPFS is a 5MP HD analog audio turret camera designed for indoor surveillance applications such as homes, shops, offices, apartments, hospitals and educational institutions.
Its 5MP CMOS image sensor produces clear and detailed video at a maximum resolution of 2560 × 1944 pixels. The camera supports video recording at up to 20 frames per second at 5MP resolution when connected to a compatible DVR.
The built-in microphone supports Audio over Coax, allowing video and audio signals to be transmitted through the same coaxial cable. A compatible DVR with Audio over Coax support is required to record audio.
Smart IR technology provides clear black-and-white night surveillance at distances up to 20 metres. The camera automatically switches between day and night modes using an IR-cut filter.
Digital WDR and 2D digital noise reduction help improve image clarity in backlit and low-light environments. Brightness, sharpness, mirror mode and Smart IR can be adjusted through the camera menu.
The camera supports four switchable video signals: TVI, AHD, CVI and CVBS. This provides compatibility with various analog HD surveillance systems.
Its compact turret design is suitable for indoor ceiling or wall installation.
Key Features
- 5MP HD analog indoor turret camera
- Maximum resolution: 2560 × 1944
- 5MP video recording at up to 20fps
- Built-in microphone
- Audio over Coax support
- Smart IR night vision up to 20 metres
- 2.8mm, 3.6mm or 6mm fixed-lens options
- TVI, AHD, CVI and CVBS switchable output
- Digital WDR
- 2D digital noise reduction
- ICR day-and-night switching
- Auto, colour and black-and-white modes
- Adjustable brightness and sharpness
- 12V DC power supply
- Compact plastic turret housing
- Suitable for indoor installation
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Hikvision |
| Model | DS-2CE76H0T-ITPFS |
| Product type | HD Analog Audio Indoor Fixed Turret Camera |
| Image sensor | 5MP CMOS |
| Maximum resolution | 2560 × 1944 |
| TVI frame rate | 5MP at 20fps |
| AHD frame rate | 5MP at 20fps |
| Minimum illumination | 0.01 Lux at F1.2, AGC ON |
| Night illumination | 0 Lux with IR |
| Lens options | 2.8mm, 3.6mm or 6mm fixed lens |
| Lens mount | M12 |
| 2.8mm field of view | H: 85.5°, V: 63.7°, D: 110.7° |
| 3.6mm field of view | H: 80.1°, V: 63.7°, D: 105.9° |
| 6mm field of view | H: 57.1°, V: 43.1°, D: 72.5° |
| Day and night | ICR |
| Day/night modes | Auto, Colour and Black & White |
| Night vision | Smart IR up to 20 metres |
| Audio | Built-in microphone |
| Audio transmission | Audio over Coax |
| Video output | TVI/AHD/CVI/CVBS switchable |
| Wide dynamic range | Digital WDR |
| Noise reduction | 2D DNR |
| White balance | ATW/Manual |
| Image settings | Brightness, sharpness, mirror and Smart IR |
| Angle adjustment | Pan 0°–360°, Tilt 0°–75°, Rotation 0°–360° |
| Communication | HIKVISION-C |
| Power supply | 12V DC ±25% |
| Maximum power consumption | 3.7W |
| Housing material | Plastic |
| Recommended environment | Indoor |
| Operating temperature | −40°C to 60°C |
| Operating humidity | 90% or less, non-condensing |
| Dimensions | Ø84.6 × 78.9mm |
| Weight | Approximately 140.5g |
